Flat Surface Solar fixing Kits

Description

Flat Surface Solar Panel Mounting Kits

Our Flat Surface Solar Panel Mounting Kits provide a practical solution for installing solar panels on suitable flat roofs and other appropriate flat surfaces.

The system is designed to provide a secure method of mounting solar panels without drilling through the roof covering, where a non-penetrating ballast-mounted system is appropriate.

These systems can be used on suitable garages, shelters and other flat surfaces, subject to the requirements of the individual installation.

Flat Roof Solar Panel Mounting

When installing solar panels on a flat roof, the mounting system must be suitable for both the roof covering and the proposed solar panel arrangement.

Our flat surface solar mounting systems use ballast-weighted mounting configurations, helping avoid unnecessary penetration of the roof covering.

The correct configuration depends on the proposed panel layout and the characteristics of the building and roof.

S Dome Flat Roof Solar Mounting

The S Dome system is designed for solar panels facing approximately south and installed in a landscape orientation.

The system uses ballast weighting to secure the solar panel mounting arrangement on the flat surface.

D Dome Flat Roof Solar Mounting

The D Dome system is designed for east/west-facing solar panel arrangements, with the panels installed in a landscape orientation.

This configuration can be useful where the available roof area or desired solar generation arrangement makes an east/west layout appropriate.

Ballast Calculation

Because these are ballast-weighted systems, we need information about the proposed installation to determine the appropriate ballast requirements.

When ordering, please provide as much information as possible, including:

• Solar panel dimensions
• Number of solar panels
• Panel layout
• Building height
• Roof covering
• Parapet wall height, where applicable

This information is required to establish the appropriate ballast requirements for the proposed installation.

Please provide these details when ordering so that the correct equipment can be supplied.

Flat Surface Solar Fixing Kits

The mounting system can be suitable for a range of flat-surface applications, including:

• Flat roofs
• Garages
• Shelters
• Other suitable flat surfaces

The suitability of the roof or surface must be considered before selecting the mounting system.

Solar Panels

Solar panels are not included unless specifically stated in the selected product configuration.

If you require solar modules, see our Solar Panels range.

When you place the order give us as much information as possible regarding the surface covering you will be placing the flat roof fixing kit onto. That way we will send you the correct equipment to suit the project.

S dome: Flat roof surface solar panel fixing system designed for south facing PV panels, these can be positioned in landscape orientation ballast weighted.	D dome: Flat surface solar kits, flat surface panel fixing system designed for East/West facing PV panels, in landscape orientation ballast weighted.

Installation Video

Alternative Ground Mounted Solar System

For installations where a ground-mounted rather than ballast-weighted system is more appropriate, see our:

Ground Mounted Solar Panel Fixing Kits
