Pan tile solar PV fixing kit for securely mounting fourteen solar panels to a tiled roof, providing the essential roof fixing components for a 14-panel installation. Solar Panel Frame Sizes. Our fixing brackets can accommodate solar module frames in the following sizes (30mm – 43mm) in black or silver finish. Please confirm the module frame thickness when ordering.
The Pan Tiled Solar module fixing kit, suitable for an fourteen panel 3.5kw assembly.
With every one of these Fourteen panel solar pan tile roof-fixing kits, you will find included every part required, to suit a concrete tiled roof covering. We can supply a complete PV pantile fixing kit will suit any standard Solar modules.
Our stocks of fixing brackets are suitable for the 30-43mm silver or black modules.
If you require our optional size module fixing brackets. Please advise the module size to match our ranges of mid and end clips above.
This example is to fix 14 photovoltaic solar modules in a portrait orientation onto a concrete tile roof.
14 Panel Pan Tile Fixing Kit Components 2 rows of 7 portrait
Component
Purpose
Pan tile roof brackets
Secure the mounting system to the tiled roof
Stainless steel fixing screws
Secure the roof brackets
Aluminium PV rails
Support the solar panels
Rail T bolts and nuts
Secure the rails to the roof brackets
Solar panel mid clamps
Secure adjacent panels
Solar panel end clamps
Secure the outer panels
Rail connectors where required
Join PV rails where additional rail length is required
Solar cable clips
Secure PV cables to the mounting system
Solar PV Systems
Solar PV Systems supplies solar panel mounting kits and solar PV fixing equipment across the UK.
We supply the equipment and technical information for customers undertaking their own solar projects or working with their chosen installer. We do not provide installation services.
Pan Tile PV fixing kits 14 panels
£1,405.00
Pan tile solar PV fixing kit for securely mounting fourteen solar panels to a tiled roof, providing the essential roof fixing components for a 14-panel installation. Solar Panel Frame Sizes. Our fixing brackets can accommodate solar module frames in the following sizes (30mm – 43mm) in black or silver finish. Please confirm the module frame thickness when ordering.
Description
The Pan Tiled Solar module fixing kit, suitable for an fourteen panel 3.5kw assembly.
With every one of these Fourteen panel solar pan tile roof-fixing kits, you will find included every part required, to suit a concrete tiled roof covering. We can supply a complete PV pantile fixing kit will suit any standard Solar modules.
Our stocks of fixing brackets are suitable for the 30-43mm silver or black modules.
If you require our optional size module fixing brackets. Please advise the module size to match our ranges of mid and end clips above.
This example is to fix 14 photovoltaic solar modules in a portrait orientation onto a concrete tile roof.
14 Panel Pan Tile Fixing Kit Components 2 rows of 7 portrait
Solar PV Systems
Solar PV Systems supplies solar panel mounting kits and solar PV fixing equipment across the UK.
We supply the equipment and technical information for customers undertaking their own solar projects or working with their chosen installer. We do not provide installation services.
Link to all solar panel fixing kits: Solar PV Fixing Kits UK | Roof & Ground Solar Mounting
